Located in Hyderabad, India, Dhruv Metals is a well-known producer and supplier of high-performance Incoloy 330 bars and rods, which are distinguished by their remarkable resistance to oxidising conditions and high temperatures. These nickel-iron-chromium alloy bars provide exceptional corrosion resistance and structural integrity, making them ideal for use in harsh industrial settings. Incoloy 330 bars and rods that satisfy international quality standards are offered by Dhruv Metals in a range of sizes and finishes. Dhruv Metals is dedicated to precise manufacturing, timely delivery, and offering customised solutions to meet a variety of demanding engineering requirements. The company supplies a wide range of products to the petrochemical, heat treatment, and furnace industries.
Nickel (34–37%), chromium (17–20%), and iron (balance) make up the majority of Incoloy 330 bars and rods, with smaller amounts of silicon (1–1.5%), manganese, and carbon. Excellent resistance to oxidation, carburisation, and heat shock is guaranteed by this composition. In terms of mechanical properties, Incoloy 330 offers a tensile strength of roughly 655 MPa, a yield strength of roughly 290 MPa, and an elongation of roughly 45%. Up to 1150°C, it retains its strength and mechanical stability. It is appropriate for high-temperature structural applications under demanding service conditions due to its exceptional creep and stress rupture characteristics.
| Grade | Incoloy 330 – UNS N08330 |
|---|---|
| Specification | ASTM B511 UNS N08330, AMS 5716, ASTM B511, ASME SB511 |
| Round bar size | Diameter: 3-~330mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Round Bar Standard Dimensions | Diameter / Height: |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | Incoloy 330 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | Incoloy 330 Rod,Channel Bar, Forging, Precision Ground Bar, Flat Bar, Round, Rod, T-Bar, Square, Blocks, Round Rod, Rings, Hollow, Threaded, Half Round Bar, Profiles, Triangle, Rectangle, Hex (A/F), Billet, Ingot, I/H Bar etc. |
| Our stockyad location for fast delivery across India | Shivamogga, Agra, Ahmedabad, Mumbai, Dhanbad, Thiruvananthapuram, Bengaluru, Tiruchirappalli, Pune, Noida, Tirunelveli, Bhubaneswar, Hyderabad , Coimbatore, Pimpri-Chinchwad, Hyderabad, Navi Mumbai |
| Our Incoloy 330 Round bar conforms to NACE MR0175/ISO 15156 | |
|
Element |
Average Nominal % |
|---|---|
|
Chromium |
18.00 – 22.00 |
|
Nickel |
34.00 37.00 |
|
Carbon |
0.08 Max |
|
Silicon |
1.00 – 1.50 |
|
Manganese |
2.00 Max |
|
Phosphorus |
0.03 Max |
|
Sulfur |
0.03 Max |
|
Copper |
1.00 Max |
|
Iron |
Balance |
|
Tensile Strength – ksi (min.) |
0.2% Offset Yield Strength – ksi (min.) |
Elongation in 2 inches – % (min.) |
Hardness – Rockwell B |
|---|---|---|---|
|
70 |
30 |
30 |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Incoloy 330 | 1.4886 | N08330 |
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
Because of their remarkable oxidation and thermal resistance, Incoloy 330 Bars and Rods are frequently utilised in corrosive and high-temperature settings. Common uses include conveyor systems, retorts, muffles, furnace fixtures and heat treatment equipment. They are utilised in reformer tubes, cracking furnace internals, and catalyst support grids in the petrochemical and refining sectors. They are perfect for components subjected to reducing atmospheres and cyclic heating because of their resistance to carburisation. They are also used in thermal processing equipment, cement factories, and power generation. Long-term dependability and structural stability are guaranteed by Incoloy 330’s resilience and performance in harsh environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
