Dhruv Metals, based in Hyderabad, India, has built a solid reputation as a manufacturer and supplier of top-notch Inconel 686 Bars and Rods, specifically designed to thrive in extreme conditions. These products are celebrated for their exceptional corrosion resistance and strength, making them a go-to choice in industries like chemical processing, marine applications, and pollution control. Crafted with cutting-edge technology and rigorous quality assurance measures, our offerings are all about durability, precision, and performance. With a strong dedication to excellence, Dhruv Metals stands out as a trustworthy source for Inconel 686 Bars and Rods that not only meet international standards but also cater to specific customer needs.
Inconel 686 Bars and Rods primarily consist of nickel, enriched with significant amounts of molybdenum (20–23%), chromium (19–23%), and trace elements like iron, tungsten, cobalt, and nitrogen. This alloy is renowned for its remarkable resistance to a wide array of harsh corrosive environments, including potent oxidizers, reducing acids such as hydrochloric acid, and crevice corrosion. On the mechanical side, Inconel 686 boasts high tensile strength, excellent weldability, and outstanding performance in high-pressure, high-temperature scenarios.
| Element | Content (%) |
|---|---|
| Nickel, Ni | 59 |
| Chromium, Cr | 19-23 |
| Molybdenum, Mo | 15-17 |
| Iron, Fe | ≤ 5 |
| Tungsten, W | 3.0-4.40 |
| Manganese, Mn | ≤ 0.75 |
| Phosphorous, P | ≤ 0.040 |
| Sulfur, S | ≤ 0.020 |
| Titanium, Ti | 0.020-0.25 |
| Carbon, C | ≤ 0.010 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 721.9 MPa | 104700 psi |
| Yield strength (@strain 0.200%) | 364 MPa | 52800 psi |
| Elastic modulus | 207 GPa | 30000 ksi |
| Shear modulus | 77 GPa | 11200 ksi |
| Poisson’s ratio | 0.34 | 0.34 |
| Elongation at break | 71% | 71% |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 721.9 MPa | 104700 psi |
| Yield strength (@strain 0.200%) | 364 MPa | 52800 psi |
| Elastic modulus | 207 GPa | 30000 ksi |
| Shear modulus | 77 GPa | 11200 ksi |
| Poisson’s ratio | 0.34 | 0.34 |
| Elongation at break | 71% | 71% |
| Properties | Metric | Imperial |
|---|---|---|
| Thermal expansion co-efficient (@21-100°C/69.8-212°F) | 11.97 µm/m°C | 6.650 µin/in°F |
Yes, Inconel 686 Bars/Rods are designed to perform exceptionally well in high-temperature environments up to 980°C.
Yes, Inconel 686 bars/rods are weldable using standard techniques, but preheating and specialized filler materials are recommended to ensure strong, corrosion-resistant welds.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@dhruvmetals.co.in
These Inconel 686 Bars and Rods find extensive applications across various sectors, including chemical processing, flue gas desulfurization systems, marine engineering, and waste treatment facilities. They are particularly suited for components that face tough chemical environments, such as heat exchangers, reactor vessels, scrubbers, and piping systems. Thanks to their ability to endure aggressive corrosion and mechanical stress, they are the preferred choice in situations where standard stainless steels and other alloys might falter. Dhruv Metals provides Inconel 686 Bars and Rods that guarantee exceptional reliability, longevity, and resistance, even in the most challenging industrial settings.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
