Dhruv Metals, a prominent manufacturer and supplier located in Hyderabad, India, specializes in top-notch Stainless Steel 316 Hex Bars and Rods, crafted for exceptional corrosion resistance and strength. These hexagonal bars are produced in line with ASTM A276 and A479 standards, ensuring they perform brilliantly in marine, chemical, and industrial settings. With their precise dimensions and excellent machinability, SS 316 hex bars are perfect for structural and fastening applications. Dhruv Metals prides itself on delivering consistent quality, competitive pricing, and timely delivery, serving a variety of industries such as pharmaceuticals, food processing, shipbuilding, and petrochemicals.
The Stainless Steel 316 Hex Bars and Rods from Dhruv Metals contain 16–18% Chromium, 10–14% Nickel, and 2–3% Molybdenum, which significantly boosts their resistance to pitting and crevice corrosion. They also include controlled amounts of Manganese, Silicon, and Carbon. In terms of mechanical properties, they boast a tensile strength of 515–750 MPa, a yield strength of at least 205 MPa, and an elongation of 40%. With a density of 7.98 g/cm³, these bars exhibit excellent toughness and weldability. SS 316 retains its strength even in high-pressure and high-temperature conditions, making it a go-to choice for aggressive chemical and chloride-rich environments.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316 | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 0.03 max | 0.75 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | – | – | 515 Min | 205 Min | 40% Min |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 316 Hex Bars and Rods are extensively utilized in marine engineering, chemical processing, and pharmaceutical manufacturing, thanks to their remarkable corrosion resistance in chloride and acidic environments. They are ideal for fasteners, valves, shafts, pump components, and structural supports that face corrosive conditions. In the food and beverage sector, SS 316 guarantees a hygienic and contamination-free operation. The construction and oil & gas industries rely on these rods for pipelines, equipment supports, and offshore structures. Their durability and strength make them a reliable choice for various demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
