Based in Hyderabad, India, Dhruv Metals is a reputable producer and supplier of stainless steel 430 flat bars, providing affordable and long-lasting solutions for a range of commercial and industrial applications. SS 430 is a ferritic stainless steel that is well-known for its exceptional formability, corrosion resistance, and aesthetic finish. It is perfect for non-critical structural and decorative applications. Dhruv Metals guarantees premium raw materials, accurate measurements, and conformity to global norms. Serving industries like interior fabrication, construction, automotive, and kitchenware, the company is dedicated to providing premium flat bars with timely service and satisfied customers in India and overseas markets.
Chromium (16–18%), iron as the base element, and trace amounts of manganese, silicon, and carbon (≤0.12%) make up the majority of stainless steel 430 flat bars. Although heat treatment cannot harden this ferritic grade, it offers good resistance to oxidation and corrosion. SS 430 has an elongation of up to 22%, a yield strength of 200–250 MPa, and a tensile strength of roughly 450–600 MPa. In mild conditions, it exhibits outstanding resistance to stress corrosion cracking, good ductility, and moderate toughness. The flat bars can be readily machined and are appropriate for mild welding and cold working.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 430 | 0.12 | 18.0 | 1.25 | – | 0.06 | 0.15 | 1.00 |
| Element | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness (Brinell (HB) max) |
| SS 430 | 552 | 379 | 25 | 262 |
| Flat Bar | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.49 | 1.60 |
| 18 | 0.62 | 2.02 |
| 20 | 0.76 | 2.49 |
| 22 | 0.92 | 3.02 |
| 25 | 1.19 | 3.90 |
| 28 | 1.49 | 4.89 |
| 28 | 1.49 | 4.89 |
| 30 | 1.71 | 5.61 |
| 32 | 1.95 | 6.38 |
| 36 | 2.46 | 8.08 |
| 38 | 2.74 | 9.00 |
| 40 | 3.04 | 9.97 |
| 45 | 3.85 | 12.62 |
| 50 | 4.75 | 12.62 |
| 56 | 8.96 | 19.55 |
| 60 | 6.84 | 22.44 |
| 65 | 8.03 | 26.34 |
| 70 | 9.31 | 30.54 |
| 75 | 10.69 | 35.06 |
| 80 | 12.16 | 39.89 |
| 90 | 15.39 | 50.49 |
| 100 | 19 | 62.34 |
Applications requiring moderate corrosion resistance, magnetic qualities, and an appealing appearance frequently use stainless steel 430 flat bars. They are utilised for exhaust system parts, brackets, and trim in the automotive industry. SS 430 is used in the architectural and construction industries for decorative structures, handrails, and interior panelling. Because of its oxidation resistance and ease of cleaning, it is also frequently found in commercial food equipment, sinks, countertops, and kitchen appliances. Furthermore, SS 430 can be used in hardware components, storage tanks, and ventilation systems that don’t require harsh chemicals or extremely high temperatures.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
