Dhruv Metals stands out as a leading manufacturer and supplier of Titanium Gr 1 Forgings in Hyderabad, India. We take pride in delivering top-notch products that are engineered for high performance in critical applications. Titanium Grade 1 is renowned for its remarkable corrosion resistance, lightweight properties, and impressive strength-to-weight ratio, making it a go-to choice across various industries. Our forgings are crafted using state-of-the-art technology and comply with international quality standards like ASTM B381. At Dhruv Metals, we guarantee precise dimensions, tight tolerances, and tailored solutions to meet a wide range of industrial needs. Our Titanium Gr 1 Forgings are highly regarded for their reliability in even the most demanding operational settings.
Titanium Gr 1 Forgings consist of 99.5% pure titanium, with minimal traces of elements such as iron (max 0.2%), oxygen (max 0.18%), carbon, nitrogen, and hydrogen. It’s the softest and most ductile among all titanium grades, providing excellent formability. The mechanical properties include a tensile strength of about 240 MPa, yield strength of 170 MPa, and an elongation of 24%, with a Brinell hardness of roughly 70 HB. This unique blend of characteristics makes it perfect for applications that demand high corrosion resistance, particularly in marine and chemical processing settings.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | O | N | Fe | H | Ti | I |
| Min | – | – | – | – | – | 99.095 | – |
| max | 0.080 | 0.18 | 0.030 | 0.2 | 0.015 | 100 | 0.2 |
| Grades | Tensile KSI Min | Yield KSI Min/Max | % Elongation Min |
| Titanium Gr 1 | 35 | 25/45 | 24 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Grade 1 | 3.7025 | R50250 |
Titanium Gr 1 Forgings find extensive use in industries where corrosion resistance is vital, especially in environments rich in oxidizing agents and chlorides. They are commonly found in heat exchangers, desalination plants, aerospace components, medical implants, marine hardware, and chemical processing equipment. Their biocompatibility also makes them ideal for surgical instruments and orthopedic devices. The lightweight yet robust nature of Titanium Gr 1 enhances fuel efficiency in the aerospace and automotive sectors. Thanks to its excellent welding and forming capabilities, it’s widely used in architectural applications as well.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
