Dhruv Metals, located in Hyderabad, India, is a well-respected manufacturer and supplier of Titanium Grade 11 Forgings. They pride themselves on delivering top-notch quality and precision-engineered components that are perfect for tough industrial settings. Titanium Grade 11 is a corrosion-resistant, alpha-phase titanium alloy that contains a bit of palladium, which boosts its performance in highly reducing and acidic conditions. It’s celebrated for its excellent weldability, formability, and resistance to crevice and pitting corrosion, making it a fantastic choice for applications in marine, chemical, and power generation sectors. Dhruv Metals guarantees that all their forgings comply with strict ASTM B381 standards and meet specific customer technical requirements with impeccable dimensional accuracy.
Titanium Grade 11 Forgings are primarily made up of titanium (about 99.5%) with a small addition of 0.12–0.25% palladium, which greatly enhances corrosion resistance in reducing acids and chloride environments. Other trace elements include iron (maximum 0.2%), carbon, nitrogen, hydrogen, and oxygen. Grade 11 boasts a tensile strength of around 345 MPa, yield strength of about 275 MPa, and an elongation of 24%, all while maintaining excellent ductility and weldability. It has a Brinell hardness of roughly 70 HB. These mechanical and chemical properties make Grade 11 particularly well-suited for extreme environments with aggressive media.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 11 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | 12 – .25 |
| Grade | Tensile Strength min | Yield Strength (0.2 % Offset) | Elongation | Reduction of Area | ||
| ksi | Mpa | ksi | Mpa | min % | min % | |
| 11 | 35 | 240 | 25 | 170 | 24 | 30 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52550 |
Titanium Grade 11 Forgings are widely used in chlorate production, chemical processing plants, heat exchangers, offshore oil and gas operations, and desalination systems, thanks to their outstanding resistance to crevice and pitting corrosion. Their remarkable ability to withstand reducing acids like hydrochloric and sulfuric acid makes them perfect for acid pickling equipment, pressure vessels, and electrochemical systems. In power plants, they find applications in condenser tubing and cooling systems. With their mechanical strength and anti-corrosive properties, Titanium Grade 11 is also a popular choice in marine environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
